€4,465.00
Available in 21 days, Lieferzeit 1 - 3 Arbeitstage
Product information
• 4 deep frames side bar length up to 29 cm / 8 shallow frames side bar length up to 14.5 cm
• Frame sizes: Zander, German Standard, Langstroth, Dadant, Zander-Dadant, Freudenstein, Gerstung, Kuntzsch, Austrian Breitwabe
Technical details:
• Emergency stop botton
• Safety device with lid lock
• Top drive motor 180 W / 230 V
• Fully automatic speed control with wall holder
• Hinged acrylic glass lid halfs
• Inner tank Ø 77 cm, welded bottom without gap
• Tank bottom with slope to the outlet
• Frame pocket size 30 cm x 45 cm
• Slots for frame lugs
• Material: Stainless steel
• Loading height: 110 cm
• Total height: 127 cm
• Distance from the floor to the honey tap: 38 cm
• Outlet: 2" honey tap, welded at bottom level
Weight without/with wrapping: 83 / 108 kg
Packed on a wooden pallet
Chargeable weight: 108 kg
Tripod (5055000) for speed control has to be ordered separatly!
| Capacity of frames: | 4 Ganz-/8 Halbrahmen |
|---|---|
| Diameter: | 77 cm |
| Frame size: | Dadant US (Honigraum) 482 x 141 mm, Deutsch Normal 394 x 223 mm, Deutsch Normal halb 394 x 110 mm, Freudenstein 338 x 200 mm, Gerstung 260 x 410 mm, Kuntzsch 330 x 250 mm, Langstroth 482 x 232 mm, Zander 477 x 220 mm, Zander shallow 477 x 110 mm |
| Motor power: | 180 W / 230 V |
| Outlet: | Quetschhahn 2" |
| Side bar length max.: | 29/14,5 cm |
Login
accessories
Please note: Only for extractors building year 2021 or later. Plastic sealant for extractors with top drive, for example manual drive or with motor on top.This sealant is to cover the bottom bearing while cleaning the tank.Colour: yellow
Food grade grease for the bottom bearing.Suitable for all CFM honey extractors for re-greasing the bottom bearing for optimum rotation of the honeycomb cage.For regular maintenance of your honey extractor.Contents: tin with 20 g
Content: 0.02 Kilogramm (€325.00 / 1 Kilogramm)
