Self-Turning Honey Extractors with Top Drive
Flexible and high-performance beekeeping equipment
A self-turning honey extractor with top drive offers efficient and convenient honey extraction for modern apiaries. In this design, the motor is mounted as a top drive on a sturdy crossbeam above the honey extractor. This setup ensures that the entire drive system remains easily accessible at all times, allowing for straightforward maintenance and cleaning of the honey extractor.
The top drive unit can be quickly and easily detached from the crossbeam using practical wing screws. This significantly simplifies cleaning and ensures maximum hygiene in beekeeping equipment. Self-turning honey extractors with top drive are ideal for both hobby and professional beekeepers who value durable stainless steel honey extractors, easy handling, and reliable technology. Discover high-quality honey extractors for purchase for efficient and sustainable honey harvesting.
The beginner model of our CFM-Euro-Self-turning extractors with "Whispering Witch". With this honey extractor the annoying manual turning of the frames is omitted. The frame basket is made of wire mesh bars and a turning device. With an inner tank Ø of just 63 cm, this self-turning extractors is one of our narrowest models.Why "Whispering Witch"? Because this drive is amazingly quiet even at full speed. In addition to the superb quietness of the drive, the comfortable operation is also a major advantage. With a rotary knob you have everything under control – can it be easier?Of course this extractor is also equipped with a security device.Suitable for:• 4 deep frames up to 23 cm side bar length • Frame sizes: Zander, German Standard, Langstroth• Direct drive with security switch• Motor power 40 W / 230 V• Very quiet drive even at full speed• Speed control 80 - 350 rpm• Hinged acrylic glass lid halves• Inner tank Ø 63 cm, welded bottom without gap• Tank bottom with slope to the outlet• Outlet: 1 1/2" honey tap, welded at bottom level• Handles at the lower end of the tank• Frame pockets made of wire mesh bars 24 cm x 41 cm• Material: Edelstahl-Rostfrei• Loading height: 100 cm• Total height: 130 cm• Distance from floor to the tap 38 cmIncluded in the delivery:1 pack with one socket wrench no. 13 and a yellow sealant for the bottom bearing.Weight with/without wrapping: 66 kg / 43 kgWrapping: cardboard boxChargeable weight: 66 kgSpare parts and accessories:Item no. 6000070 Ball for bearingItem no. 6300061 Rubber feetItem no. 6000074 Food lubricant grease for bottom bearing 20 gItem no. 23045007 Sealant for bottom bearingAcrylic glass lid half on request
The beginner model of our CFM-Euro-Self-turning extractors. With this honey extractor the annoying manual turning of the frames is omitted. The frame basket is made of wire mesh bars and a turning device. With an inner tank Ø of just 63 cm, this self-turning extractors is one of our narrowest models. The left and right turn can easily be adjusted with a lever. Of course this extractor is also equipped with a security device.Suitable for:• 4 deep frames up to 23 cm side bar length • Frame sizes: Zander, German Standard, LangstrothTechnical details:• Top drive with security switch• Motor power 110 W / 230 V• Left and right turn• Hinged acrylic glass lid halves• Inner tank Ø 63 cm, welded bottom without gap• Tank bottom with slope to the outlet• Outlet: 1 1/2" honey tap, welded at bottom level• Handles at the lower end of the tank• Frame pockets made of wire mesh bars 24 cm x 41 cm• Material: Edelstahl-Rostfrei• Total height: 124 cm• Distance from floor to the tap 38 cmIncluded in the delivery:1 pack with one socket wrench no. 13 and a yellow sealant for the bottom bearing.Weight with/without wrapping: 44 kg / 66 kgWrapping: cardboard boxChargeable weight: 66 kg Spare parts and accessories:Item no. 6000070 Ball for bearingItem no. 6300061 Rubber feetItem no. 6000074 Food lubricant grease for bottom bearing 20 gItem no. 23045007 Sealant for bottom bearingAcrylic glass lid half on request
Suitable for:• 4 deep frames side bar length up to 24 cm• frame sizes: Zander, German Standard, Langstroth, FreudensteinTechnical details:• Emergency stop botton• Safety device with lid lock• Top drive motor 180 W / 230 V• Fully automatic speed control with wall holder• Hinged acrylic glass lid halfs• Inner tank Ø 72 cm, welded bottom without gap• Tank bottom with slope to the outlet• Frame pocket size 25 cm x 45 cm• Slots for frame lugs• Material: Stainless steel• Loading height: 110 cm• Total height: 127 cm• Distance from the floor to the honey tap: 38 cm• Outlet: 2" honey tap, welded at bottom levelWeight without/with wrapping: 72 kg / 95 kgPacked on a wooden palletChargeable weight: 95 kg Tripod (5055000) for speed control has to be ordered separatly!
This CFM-Euro-Self-turning extractor is suitable for 4 frames Zander, German Standard or Langstroth. With an inner tank Ø of just 63 cm, this self-turning extractors is one of our narrowest models.The low-noise top drive gear motor offers you the possibility to switch from right to left (or vice versa) via a tilt switch. As soon as you change the direction with the switch, the drive automatically stops and then starts again in the other direction. The rotary knob can be steplessly adjusted. The honey extractor is also equipped with a safety device so that the lid cannot be opened during the extraction process. This mechanism is only released when the basket comes to a complete stop.Suitable for:• 4 deep frames up to 23 cm side bar length • Frame sizes: Zander, German Standard, LangstrothTechnical details:• Security device with lid lock• Flat gear motor 270 W / 230 V• Left / right turn• Speed continously adjustable• Hinged acrylic glass lid halves• Inner tank Ø 63 cm, welded bottom without gap• Tank bottom with slope to the outlet• Outlet: 1 1/2" honey tap, welded at bottom level• Handles at the lower end of the tank• Frame pockets made of wire mesh bars 24 cm x 41 cm• Material: Edelstahl-Rostfrei• Total height: 126 cm• Distance from floor to the tap 38 cmIncluded in the delivery:1 pack with one socket wrench no. 13 and a yellow sealant for the bottom bearing.Weight with/without wrapping: 45 kg / 65 kgWrapping: cardboard boxChargeable weight: 65 kg Spare parts and accessories:Item no. 6000070 Ball for bearingItem no. 6300061 Rubber feetItem no. 6000074 Food lubricant grease for bottom bearing 20 gItem no. 23045007 Sealant for bottom bearingAcrylic glass lid half on request
The low-noise top drive gear motor offers you the option of switching from clockwise to anticlockwise rotation (or vice versa) by means of a toggle switch. As soon as you change the running direction by means of a switch, the drive brakes automatically and then starts up again in the other direction. The speed can be infinitely adjusted by means of a rotary knob. The honey extractor is also equipped with a safety device so that the lid cannot be opened during the extracting process. This mechanism is only released when the cage has come to a complete standstill.Suitable for:• 4 deep frames side bar length up to 27 cm• Frame sizes: Zander, German Standard, Langstroth, Gerstung, Kuntzsch, Austrian BreitwabeTechnical details:• Safety device with lid lock• Top drive gear motor 270 W / 230 V• Left / right turn• Speed infinitely adjusted• Hinged acrylic glass lid halfs• Inner tank Ø 72 cm, welded bottom without gap• Tank bottom with slope to the outlet• Outlet: 2" honey tap, welded at bottom level• Frame pocket size 28 cm x 45 cm• Material:stainless steel• Loading height: 112 cm• Total height: 128 cm• Distance from the floor to the honey tap: 38 cmWeight: without/with wrapping: XX kg / XX kgPacked on a wooden pallet
Suitable for:• 4 deep frames side bar length up to 29 cm / 8 shallow frames side bar length up to 14.5 cm• Frame sizes: Zander, German Standard, Langstroth, Dadant, Zander-Dadant, Freudenstein, Gerstung, Kuntzsch, Austrian BreitwabeTechnical details:• Emergency stop botton• Safety device with lid lock• Top drive motor 180 W / 230 V• Fully automatic speed control with wall holder• Hinged acrylic glass lid halfs• Inner tank Ø 77 cm, welded bottom without gap• Tank bottom with slope to the outlet• Frame pocket size 30 cm x 45 cm• Slots for frame lugs• Material: Stainless steel• Loading height: 110 cm• Total height: 127 cm• Distance from the floor to the honey tap: 38 cm• Outlet: 2" honey tap, welded at bottom levelWeight without/with wrapping: 83 / 108 kgPacked on a wooden palletChargeable weight: 108 kg Tripod (5055000) for speed control has to be ordered separatly!
Suitable for:• 6 deep frames side bar length up to 24 cm• Frame sizes: Zander, German Standard, Langstroth, FreudensteinTechnical details:• Emergency stop botton• Safety device with lid lock• Top drive motor 180 W / 230 V• Fully automatic speed control with wall holder• Hinged acrylic glass lid halfs• Inner tank Ø 77 cm, welded bottom without gap• Tank bottom with slope to the outlet• Frame pocket size 25 cm x 45 cm• Slots for frame lugs• Material: Stainless steel• Loading height: 110 cm• Total height: 127 cm• Distance from the floor to the honey tap: 38 cm• Outlet: 2" honey tap, welded at bottom levelWeight without/with wrapping: 88kg / 110 kgPacked on a wooden palletChargeable weight: 110 kg Tripod (5055000) for speed control has to be ordered separatly!
This CFM-Euro-Self-turning extractor is suitable for 4 frames Zander, German Standard, Langstroth and Freudenstein.The low-noise top drive gear motor offers you the possibility to switch from right to left (or vice versa) via a tilt switch. As soon as you change the direction with the switch, the drive automatically stops and then starts again in the other direction. The rotary knob can be steplessly adjusted. The honey extractor is also equipped with a safety device so that the lid cannot be opened during the extraction process. This mechanism is only released when the basket comes to a complete stop.Suitable for:• 4 deep frames up to 23 cm side bar length • Frame sizes: Zander, German Standard, LangstrothTechnical details:• Security device with lid lock• Flat gear motor 270 W / 230 V• Left / right turn• Speed continously adjustable• Hinged acrylic glass lid halves• Inner tank Ø 72 cm, welded bottom without gap• Tank bottom with slope to the outlet• Outlet: 1 1/2" honey tap, welded at bottom level• Handles at the lower end of the tank• Frame pockets made of wire mesh bars 25 cm x 45 cm• Material: Edelstahl-Rostfrei• Loading height: 112 cm• Total height: 128 cm• Distance from floor to the tap 38 cmIncluded in the delivery:1 pack with one socket wrench no. 13 and a yellow sealant for the bottom bearing.Weight with/without wrapping: 66 kg / 90 kgWrapping: cardboard boxChargeable weight: 90 kg Spare parts and accessories:Item no. 6000070 Ball for bearingItem no. 6300059 Rubber feetItem no. 6000074 Food lubricant grease for bottom bearing 20 gItem no. 23045007 Sealant for bottom bearingAcrylic glass lid half on request
Suitable for:• 4 deep frames side bar length up to 27 cm• frame sizes: Zander, German Standard, Langstroth, Freudenstein, Gerstung, Kuntzsch, Austrian BreitwabeTechnical details:• Emergency stop botton• Safety device with lid lock• Top drive motor 180 W / 230 V• Fully automatic speed control with wall holder• Hinged acrylic glass lid halfs• Inner tank Ø 72 cm, welded bottom without gap• Tank bottom with slope to the outlet• Frame pocket size 28 cm x 45 cm• Slots for frame lugs• Material: Stainless steel• Loading height: 110 cm• Total height: 127 cm• Distance from the floor to the honey tap: 38 cm• Outlet: 2" honey tap, welded at bottom levelWeight: 74kgPacked on a wooden palletTripod (5055000) for speed control has to be ordered separatly!
Suitable for:• 6 deep frames side bar length up to 27 cm• Frame sizes: Zander, German Standard, Langstroth, Freudenstein, Gerstung, Kuntzsch, Austrian BreitwabeTechnical details:• Emergency stop botton• Safety device with lid lock• Top drive motor 180 W / 230 V• Fully automatic speed control with wall holder• Hinged acrylic glass lid halfs• Inner tank Ø 77 cm, welded bottom without gap• Tank bottom with slope to the outlet• Frame pocket size 28 cm x 45 cm• Slots for frame lugs• Material: Stainless steel• Loading height: 110 cm• Total height: 127 cm• Distance from the floor to the honey tap: 38 cm• Outlet: 2" honey tap, welded at bottom levelWeight: 91 kgPacked on a wooden palletChargeable weight: 130 kg Tripod (5055000) for speed control has to be ordered separatly!
*** Special price II. choice with small flaws - works perfectly ***Suitable for:• 4 deep frames side bar length up to 24 cm• frame sizes: Zander, German Standard, Langstroth, FreudensteinTechnical details:• Emergency stop botton• Safety device with lid lock• Top drive motor 180 W / 230 V• Fully automatic speed control with wall holder• Hinged acrylic glass lid halfs• Inner tank Ø 72 cm, welded bottom without gap• Tank bottom with slope to the outlet• Frame pocket size 25 cm x 45 cm• Slots for frame lugs• Material: Stainless steel• Loading height: 112 cm• Total height: 128 cm• Distance from the floor to the honey tap: 38 cm• Outlet: 2" honey tap, welded at bottom levelWeight without/with wrapping: 70 kg / 95 kgPacked on a wooden palletChargeable weight: 95 kg Tripod (5055000) for speed control has to be ordered separatly!
