Tank insulation for CFM-Steam wax melter

The steam wax melter is completely made of stainless steel. The steam is not generated in the melting tank but in the water tank beneath. This version uses a submersible tube heater to heat the water tank. • Operation via thermostatically adjustable submersible tube heater 3 kW / 230 V (30 – 110 °C)• A melting process takes approx. 40 minutes (depending on the quality of the honeycomb material)• Water volume in the water tank 19 litres • Capacity approx. 30 frames DN, Zander or Langstroth, 16 frames Dadant brood, 35 frames Dadant supers• Inner tank Ø 63 cm, welded bottom without gap• Rigit handles• Lid with silicon gasket and locking ring, seals the tank completely tight • Immersion pipe heating element adjustable via thermostat from 30 - 110°C (3000 W / 230 V)• NEW on wheels which you can lockPlease note: Wax masher and wax pot not included in the delivery!Weight without/with wrapping: 30 kg / 46 kgPacked on a wooden pallet.Chargeable weight: 46 kg Accessoires - to be ordered separately:Item number 5000321 Wax masherItem number 5000336 Wax pot

The CFM steam wax melter “Apitotal” does not produce the steam in the melting tank, but in the water tank beneath it. No electricity is required for this version. A gas burner is sufficient to operate this device. We recommend a gas burner with 14 kW (no. 6090302)• Operation with a gas burner – no electricity is needed• A melting process takes approx. 40 minutes (depending on the quality of the honeycomb material)• Water volume in the tank 19 liter• Capacity for approx. 30 frames (approx. 16 Dadant brood frames)• Inner tank Ø 63 cm, welded bottom without gap• Rigit handles• Lid with silicon gasket and locking ring, seals the tank completely tight • NEW on wheels which you can lockPlease note: Wax masher and wax pot not included in the delivery!Weight without/with: 30 kg / 40 kgPacked on a wooden pallet.Chargeable weight: 40 kg Accessoires - to be ordered separately:Item number 6090302 gas burner with 14 kWItem number 5000321 Wax masherItem number 5000336 Wax pot
